License Key
Workflow Engine requires a license key for production use. Without a key, it runs in Workflow Engine Free mode, which limits the number of schemes and threads. A license key is a string provided by OptimaJet after purchase or trial registration. Register it with WorkflowRuntime before calling Start().
Get a trial license key
You can obtain a free 30-day trial key at trial.workflowengine.io. No credit card is required.
Via the web form
- Open trial.workflowengine.io in your browser.
- Enter your company name and your business email (personal email domains such as gmail.com are not accepted).
- Click Get Trial Key.
- Check your inbox - the license key and setup instructions are sent to the email you provided.
The key has the TRIAL- prefix and unlocks all features for 30 days. When the trial expires, the runtime falls back to Workflow Engine Free mode with the same caps as an unlicensed installation.
Via API (for LLM agents and automation)
The trial portal exposes a programmatic API for agents and automated workflows. The API reference is available at trial.workflowengine.io/llms.txt.
POST https://trial.workflowengine.io/api/trial/llmContent-Type: application/json{ "email": "user@company.com", "companyName": "Company Name"}A successful response returns the license key directly and also sends it by email:
{ "success": true, "message": "Check your email. We've sent the trial license key and setup instructions.", "licenseKey": "TRIAL-..."}Limits:
- Maximum 3 trial keys per email address (lifetime).
- Business email required - personal and disposable domains are rejected.
- Rate limit: one request per email per 24 hours.
- The key is also sent by email for reference.
Purchase a commercial license key
To purchase a commercial license, contact OptimaJet at optimajet.com or sales@optimajet.com. Once you receive your key, it will begin with a customer identifier prefix (your company name for commercial keys or TRIAL- for trial keys).
Register the license key
Call the static method WorkflowRuntime.RegisterLicense once before creating any runtime instance. This is the recommended approach for console apps and worker services:
WorkflowRuntime.RegisterLicense("YOUR-LICENSE-KEY-STRING");var runtime = new WorkflowRuntime() .WithPersistenceProvider(persistenceProvider) .AsSingleServer() .Start();The key must be registered before calling .Start(). The key is validated at startup; an invalid or expired key throws InvalidLicenseException or LicenseExpiredException.
Store the key in configuration
Do not hard-code the key in source code. Read it from application configuration:
{ "WorkflowEngine": { "LicenseKey": "YOUR-LICENSE-KEY-STRING" }}string licenseKey = builder.Configuration["WorkflowEngine:LicenseKey"] ?? throw new InvalidOperationException("Workflow Engine license key is not configured.");WorkflowRuntime.RegisterLicense(licenseKey);var runtime = new WorkflowRuntime() .WithPersistenceProvider(persistenceProvider) .AsSingleServer() .Start();For production, store the key in a secrets manager (Azure Key Vault, AWS Secrets Manager, Kubernetes secrets) and inject it into configuration at runtime.
Workflow Engine Free limits
Without a license key, or with an expired key, Workflow Engine runs in Workflow Engine Free mode:
| Limit | Workflow Engine Free |
|---|---|
| Unique schemes in the process cache | 10 |
| Concurrent runtime operations (semaphore) | 4 |
| Activities, transitions, commands per scheme | Unlimited |
| Designer | Fully functional with Workflow Engine Free indicator |
Workflow Engine Free is suitable for development, evaluation, and small projects. It does not watermark or disable functionality - the scheme and concurrency limits are the only restrictions.
Verify the license at startup
Check the current license restrictions by reading WorkflowRuntime.GetLicenseRestrictions():
var restrictions = WorkflowRuntime.GetLicenseRestrictions();if (restrictions.MaxNumberOfSchemes <= 10){ logger.LogWarning( "Workflow Engine is running in Workflow Engine Free mode. " + "Scheme and thread limits apply.");}This method always returns the active restrictions - Workflow Engine Free defaults if no license key is registered, or the upgraded values if a valid key was applied.
Handle license expiry
Most license keys have an expiry date - typically 12 months from purchase. When a key expires, the runtime switches to Workflow Engine Free mode - the same limits as running without a license.
Perpetual keys do not expire. Once registered, they remain valid indefinitely.
To restore full functionality after expiry, replace the expired key with a new one in your configuration and restart the application. No database changes are needed.
For trial keys, visit trial.workflowengine.io before the current key expires.
Deploy licenses across multiple servers
In a multi-server deployment, each runtime node reads the license key from its own configuration. All nodes must use the same key. There is no per-node or per-seat licensing - the key covers the entire deployment.
See also
Workflow Engine Editions
Compare Free, commercial, and NEO editions.
Workflow Engine Features
Browse all 24 production-ready features unlocked with a license key.
Install
Set up the runtime and register your license key.
Frequently asked questions
Where do I buy or renew a license key?
Contact OptimaJet at optimajet.com or sales@optimajet.com. Licenses are available for annual subscription or perpetual purchase.
Where do I get a trial key?
Visit trial.workflowengine.io, enter your company name and business email, and click Get Trial Key. The key is sent to your email. You can also request one programmatically via POST /api/trial/llm - see trial.workflowengine.io/llms.txt for the API reference. The trial key has the TRIAL- prefix and works the same way as a commercial key for 30 days.
Can I use one license key in both staging and production?
Yes. You only need a paid license key for production environments. The same key works in staging and development - those environments do not require additional purchases.
What happens if I restart the application after the license expires?
The runtime switches to Workflow Engine Free mode - processes continue to run and new instances can be created, but the Workflow Engine Free limits apply. Renew the key and restart to restore full functionality.
Is the key validated online?
No. License validation is performed locally - the key string encodes your entitlements and is verified without a network call. The runtime does not phone home.
How is the key structured?
License keys contain a customer identifier prefix and base64-encoded license data. The prefix matches the customer identifier encoded in the data to prevent key sharing. The data includes expiry date, feature restrictions, and a cryptographic signature.
