Evaluate Get Started

Framework-Agnostic Install

Rylee Soll Rylee Soll Updated 5 min read 999 words
getting-started workflow Additional

This page shows how to install Workflow Engine in a console application, worker service, or any non-ASP.NET Core host. For ASP.NET Core projects, use the Web API install instead - it provides HTTP endpoints, built-in security, and multitenancy.

The example below uses a console application, but the same steps apply to any .NET host.

Prerequisites:

  • .NET 10 SDK
  • A running database (SQL Server, PostgreSQL, MySQL, Oracle, or MongoDB) - SQLite uses a local file and does not require a running server

Step 1: Create a new console project

Start by creating a console application with the .NET SDK:

dotnet new console -n WorkflowConsole --framework net10.0cd WorkflowConsole

Step 2: Install packages and write Program.cs

Choose your database provider. Each tab shows the NuGet packages to install and the corresponding Program.cs code.

dotnet add package WorkflowEngine.NETCore-Coredotnet add package WorkflowEngine.NETCore-ProviderForSQLite

Copy and paste the following code to replace the contents of Program.cs:

Program.cs
using System.Xml.Linq;using OptimaJet.Workflow.Core.Builder;using OptimaJet.Workflow.Core.Parser;using OptimaJet.Workflow.Core.Runtime;using OptimaJet.Workflow.Migrator;using OptimaJet.Workflow.SQLite;var connectionString = "Data Source=workflow.db";var provider = new SqliteProvider(connectionString);var workflowBuilder = new WorkflowBuilder<XElement>(    provider,    new XmlWorkflowParser(),    provider).WithDefaultCache();var runtime = new WorkflowRuntime()    .WithBuilder(workflowBuilder)    .WithPersistenceProvider(provider)    .RunMigrations()    .Start();Console.WriteLine("Workflow Runtime started. Press any key to stop.");Console.ReadKey();await runtime.ShutdownAsync();Console.WriteLine("Workflow Runtime stopped.");

The connectionString value needs to point to your database. For SQLite, the default Data Source=workflow.db creates a local file - update the path to match your project. For other providers, replace PUT YOUR CONNECTION STRING HERE with your actual connection string.

Step 4: Run and verify

Build and run the project to check that the runtime starts correctly:

dotnet run

If the runtime starts without exceptions, Workflow Engine creates all required tables in your database automatically.

Next steps

Frequently asked questions

Which NuGet packages do I need for a non-ASP.NET Core project?

Install WorkflowEngine.NETCore-Core and the persistence provider package matching your database - for example, WorkflowEngine.NETCore-ProviderForSQLite for SQLite or WorkflowEngine.NETCore-ProviderForMSSQL for SQL Server. The provider transitively pulls in WorkflowEngine.NETCore-Migrator (schema setup).

How do I initialize WorkflowRuntime without ASP.NET Core?

Create a persistence provider instance with your connection string, pass it to WorkflowBuilder, call RunMigrations() to create the required database tables, then call Start(). No DI container or web host is needed.

Does Workflow Engine create its own database tables automatically?

For SQL providers, calling RunMigrations() during initialization creates all required tables in the target database if they do not exist, and applies any pending schema updates. You do not need to run SQL scripts manually.

For MongoDB, RunMigrations() is not applicable - collections and indexes are created automatically by the provider at runtime, no explicit migration call is needed.

Can I use Workflow Engine without a database at runtime?

No. Workflow Engine persists process state, scheme definitions, timers, and history to a database. A persistence provider is required.

Previous Your First Workflow Next Integrate the Designer
